Griffco’s new Unibody pressure relief valves (leak-free relief valves) is the latest innovation to ensure leak-free connections and operation. This new design allows flexibility of changing connection types, provides ease of maintenance, and eliminates additional system components (extra unions) saving time and money. As with all of the Griffco designs, the chemical feed system is safeguarded by applying a continuous back pressure to the chemical feed pump, while also acting as an anti-siphon valve. This new construction ensures increased leak-free reliability in the rigorous service of municipal and industrial applications.
Griffco Unibody Relief Valves
2 Year Warranty
Valve Features
- Solid, robust, single-piece machined construction
- No seals or glued connections
- Anti-siphon function
- Available in PVC and CPVC
- Union style connections
- Molded Noryl top with integral hardware locking
- Vulcanized composite PTFE/EPDM diaphragm
- Adjustable up to 150 psi (10 bar)
- 4 optional pressure ratings (springs)
- Valve sizes from 1/2" to 1" or DN 15 to DN 25
- Tamper-resistant adjustment screw
Griffco Benefits
- Compact size for OEM applications
- High reliability at affordable price
- Multiple diaphragm material options
- Long diaphragm life
- Two year warranty
Available Sizes
- 1/2" to 1" or DN 15 to DN 25
Wetted Materials
- PVC
- CPVC
Unibody PRU - Specifications
| Size | Maximum Flow | Maximum Pressure | |||||
| Pulsating | Continuous | ||||||
| Inch | Metric | GPH | LPH | GPM | LPM | PSI | BAR |
| 1/2" | DN 15 | 260 | 984 | 15 | 57 | 150 | 10 |
| 3/4" | DN 20 | 300 | 1,135 | 21 | 80 | 150 | 10 |
| 1" | DN 25 | 500 | 1,890 | 26 | 98 | 150 | 10 |
Unibody PRU - Documents
| Title | Description | Date modified | Download |
|---|---|---|---|
| Data Sheet PRU (US) | Imperial | 09-14-2020 | Download |
| Data Sheet PRU (Intl) | Metric | 09-14-2020 | Download |
Unibody PRU - Dimensional Drawings
Unibody M Series 2-Port @ 180° (1/2") (DN 15)
| Title | Description | Date modified | Download |
|---|---|---|---|
| Dim PRMUB 2Port@180 Union US | 1/2" | 08-24-2020 | Download |
| Dim PRMUB 2Port@180 Union Metric | DN 15 | 08-24-2020 | Download |
